How to Create A Scatter Plot In D3.js?

10 minutes read

To create a scatter plot in D3.js, you will first need to define a scale for both the x and y axes using the D3.js scale functions. Then, you can use the D3.js select and append functions to create SVG elements for each data point in your dataset. Next, you can use the D3.js enter and append functions to bind your data to each SVG element and set their position based on the scales you defined earlier.


You can also customize the appearance of your scatter plot by changing the size, shape, and color of the data points, as well as adding axis labels and a title. Finally, you can use D3.js to add interactivity to your scatter plot, such as tooltips that display additional information when a data point is hovered over. Overall, creating a scatter plot in D3.js involves combining a variety of D3.js functions to effectively visualize your data in a clear and informative way.

Best D3.js Books to Read in May 2024

1
D3.js in Action, Third Edition

Rating is 5 out of 5

D3.js in Action, Third Edition

2
Learn D3.js 5

Rating is 4.9 out of 5

Learn D3.js 5

3
Pro D3.js: Use D3.js to Create Maintainable, Modular, and Testable Charts

Rating is 4.8 out of 5

Pro D3.js: Use D3.js to Create Maintainable, Modular, and Testable Charts

4
D3.js in Action: Data visualization with JavaScript

Rating is 4.7 out of 5

D3.js in Action: Data visualization with JavaScript

5
D3.js: Unleashing the Power of Data Visualization on the Web

Rating is 4.6 out of 5

D3.js: Unleashing the Power of Data Visualization on the Web

6
Data Visualization with D3.js Cookbook

Rating is 4.5 out of 5

Data Visualization with D3.js Cookbook

7
D3.js in Action

Rating is 4.4 out of 5

D3.js in Action

8
Integrating D3.js with React: Learn to Bring Data Visualization to Life

Rating is 4.3 out of 5

Integrating D3.js with React: Learn to Bring Data Visualization to Life

9
D3: Modern Web Visualization: Exploratory Visualizations, Interactive Charts, 2D Web Graphics, and Data-Driven Visual Representations (English Edition)

Rating is 4.2 out of 5

D3: Modern Web Visualization: Exploratory Visualizations, Interactive Charts, 2D Web Graphics, and Data-Driven Visual Representations (English Edition)

10
D3 Start to Finish: Learn how to make a custom data visualisation using D3.js

Rating is 4.1 out of 5

D3 Start to Finish: Learn how to make a custom data visualisation using D3.js


How to create a trend line in a scatter plot with D3.js?

To create a trend line in a scatter plot with D3.js, you can follow these steps:

  1. Load the D3.js library in your HTML file:
1
<script src="https://d3js.org/d3.v7.min.js"></script>


  1. Create a SVG element in your HTML file where the scatter plot will be displayed:
1
<svg width="800" height="600"></svg>


  1. Create the data for the scatter plot and trend line:
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
const data = [
  {x: 1, y: 2},
  {x: 2, y: 5},
  {x: 3, y: 3},
  {x: 4, y: 6},
  {x: 5, y: 8}
];

const trendLineData = [
  {x: 1, y: 2},
  {x: 5, y: 8}
];


  1. Create the scales for the x and y axis:
1
2
3
4
5
6
7
const xScale = d3.scaleLinear()
  .domain([0, d3.max(data, d => d.x)])
  .range([50, 750]);

const yScale = d3.scaleLinear()
  .domain([0, d3.max(data, d => d.y)])
  .range([550, 50]);


  1. Create the SVG elements for the scatter plot:
1
2
3
4
5
6
7
8
9
const svg = d3.select("svg");

svg.selectAll("circle")
  .data(data)
  .enter().append("circle")
  .attr("cx", d => xScale(d.x))
  .attr("cy", d => yScale(d.y))
  .attr("r", 5)
  .style("fill", "blue");


  1. Create the SVG elements for the trend line:
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
const line = d3.line()
  .x(d => xScale(d.x))
  .y(d => yScale(d.y));

svg.append("path")
  .datum(trendLineData)
  .attr("d", line)
  .attr("stroke", "red")
  .attr("stroke-width", 2)
  .attr("fill", "none");


  1. Now you should see a scatter plot with a trend line displayed on your web page. Feel free to customize the styling and data to fit your needs.


What are the best practices for designing a scatter plot with D3.js?

  1. Choose the right data: Make sure that the data you are using for your scatter plot is appropriate for the type of relationships you are trying to visualize.
  2. Determine the scales: Use D3.js scale functions to map your data values to the x and y axes of your scatter plot. This will ensure that the data is correctly represented on the chart.
  3. Customize the appearance: Use D3.js to customize the appearance of your scatter plot, including colors, sizes, and shapes of the data points. You can also add labels, grids, and axes to make the plot more visually appealing and informative.
  4. Add interactivity: Make your scatter plot interactive by adding features such as tooltips that display information about individual data points when the user hovers over them with their mouse. You can also add zooming and panning functionality to allow users to explore the data more effectively.
  5. Use transitions: Use D3.js transitions to smoothly animate changes in the scatter plot, such as updating the data or changing the appearance of the data points. This can help users better understand the relationships between different data points.
  6. Test and optimize: Before finalizing your scatter plot, be sure to test it on different devices and screen sizes to ensure that it is responsive and functional. Optimize the performance of your scatter plot by minimizing unnecessary rendering and calculations.


How to update a scatter plot dynamically with new data in D3.js?

To update a scatter plot dynamically with new data in D3.js, you can follow these steps:

  1. Define the initial scatter plot with your dataset and settings:
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
var dataset = [
  { x: 10, y: 20 },
  { x: 30, y: 40 },
  { x: 50, y: 60 }
];

var svg = d3.select("body").append("svg")
  .attr("width", 500)
  .attr("height", 500);

var circles = svg.selectAll("circle")
  .data(dataset)
  .enter()
  .append("circle")
  .attr("cx", function(d) { return d.x; })
  .attr("cy", function(d) { return d.y; })
  .attr("r", 5);


  1. Create a function to update the scatter plot with new data:
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
function update(data) {
  circles = svg.selectAll("circle")
    .data(data);

  circles.enter()
    .append("circle")
    .attr("cx", function(d) { return d.x; })
    .attr("cy", function(d) { return d.y; })
    .attr("r", 5);

  circles.exit().remove();
}


  1. Call the update function with new data whenever you want to update the scatter plot:
1
2
3
4
5
6
var newData = [
  { x: 70, y: 80 },
  { x: 90, y: 100 }
];

update(newData);


By following these steps, you can dynamically update a scatter plot in D3.js with new data. The update function will add new circles for the new data points and remove any existing circles that are no longer needed.
