How to Rescale A Stl Surface In Matlab?

13 minutes read

To rescale an STL surface in MATLAB, you can follow these steps:

  1. Load the STL file into MATLAB using the stlread function. This will read the surface geometry and return the vertices and faces.
  2. Calculate the centroid of the surface by averaging the coordinates of all vertices.
  3. Translate the surface data by subtracting the centroid coordinates from each vertex. This step aligns the surface with the origin.
  4. Calculate the scaling factors for each axis (x, y, and z). You can determine the desired scaling factors based on the desired size of the rescaled surface.
  5. Scale the translated surface by multiplying each vertex with the respective scaling factor. Multiply the x-coordinate of each vertex by the scaling factor for the x-axis, the y-coordinate by the scaling factor for the y-axis, and the z-coordinate by the scaling factor for the z-axis.
  6. Translate the rescaled surface back to its original position by adding the centroid coordinates to each vertex.
  7. Save the modified surface data to a new STL file using the stlwrite function, if necessary.


By following these steps, you can successfully rescale an STL surface using MATLAB.
